Chain Conveyor — installed unit, full height, portrait 1500×2000 · WEBP · shot on the line, not on white Photography pending
Overview
A Chain Conveyor moves materials using a continuous chain running over sprockets powered by a motor. Products sit directly on the chain or on fixtures attached to it, making it ideal for transporting heavy or bulky items across manufacturing and industrial settings. Its robust chain-drive construction ensures stable, consistent movement with reduced maintenance.
Features
What is built into it
- 01
Heavy-duty construction
- 02
Durable chain drive
- 03
Customizable configuration
- 04
Versatile applications
- 05
Handles large, heavy items
- 06
Stable movement
- 07
Reduced maintenance
- 08
Consistent operation
Specification
Standard ranges
Read these as the envelope, not a fixed configuration. Length, width, height, finish and drive are set per application on the GA drawing.
Chain Conveyor — GA drawing, plan and elevation, key dimensions called out SVG or PDF · 1-colour line art · dimensioned Drawing pending
- Length
- 1.5-10 m / Customized
- Width
- 300-600 mm
- Height
- 700-900 mm / Customized
- MOC
- SS 304 / MS
- Surface Finish
- SS Matt / Bead Blast or MS Painting & Powder Coating
- Speed
- 5-15 m/min
- Motor Position
- Right / Left
- Voltage
- 220 V / 415 V
- Drive Type
- Direct / Chain
- Direction
- Single
- Resting
- Levelling Pads / Wheel
Applications
Where it runs
- Transferring heavy components between workstations
- Boxes handling in warehouses
- Capping bottles
- Handling food grains
- Moving blister packs
- Transporting tablets/capsules
- Airports
- Assembly Lines
- Automobile
- Cosmetics
- E-commerce
- Electronics
- Food and Beverages
- Manufacturing
- Packaging
- Pharma
- Warehousing
- Waste Management
