The Inclined Modular Conveyor is engineered to transport products between different heights using a modular plastic belt design. Its inclined configuration optimizes vertical space while maintaining a steady product flow, elevating boxes, pouches, and cartons from ground level up to processing or packaging stations. The system combines strong grip, durability, and easy maintenance, with interlocking modular sections that support curves, inclines, and declines. Auto belt alignment via sprocket engagement ensures smooth, reliable vertical transfer, and the hygienic, low-maintenance construction suits a wide range of product types.
What is built into it
- 01
Modular, interlocking design enabling easy section replacement
- 02
Configurable for curves, inclines, and declines
- 03
Auto belt alignment with sprocket engagement
- 04
Smooth vertical transfer with space-saving design
- 05
Hygienic, durable construction requiring low maintenance
- 06
Suitable for multiple product types
- 07
Bi-directional operation with flexible motor positioning (right/left/center)
Standard ranges
Read these as the envelope, not a fixed configuration. Length, width, height, finish and drive are set per application on the GA drawing.
- Length
- 0.5-10 meters (customizable)
- Width
- 65-1200 mm
- Height
- 700-900 mm (customizable)
- Inclination
- 7.5, 15, 30, 45, 60 degrees (customizable)
- Material Construction
- SS 304 / MS / Aluminium
- Surface Finish
- SS Matt / Bead Blast / Painting & Powder Coating
- Belt Type
- Flat top, perforated, cleated, friction top, radius/curved
- Speed
- 5-30 m/min
- Motor Position
- Right / Left / Center
- Voltage
- 220V / 415V
- Drive Type
- Direct / Chain / Belt Drive
- Direction
- Bi-Directional
- Support
- Levelling Pads / Wheel
Where it runs
- Airports
- Assembly Lines
- Automobile
- Cosmetics
- E-commerce
- Electronics
- Food & Beverages
- Manufacturing
- Packaging
- Pharmaceuticals
- Warehousing
- Waste Management
- Product handling: bottles, blister packs, tablets/capsules, sheet metal parts, vaccine bottles, food grains, biscuits, and trays
