The Radius Power Roller Conveyor is a motor-driven curved conveyor system engineered to move products smoothly through directional changes while maintaining steady, consistent flow around corners. Its powered rollers ensure reliable transport of cartons, totes, boxes, and trays in automated production and packaging lines. Built for durability and low maintenance, it supports variable speed and bi-directional operation for flexible material handling.
What is built into it
- 01
Smooth curved product flow around corners
- 02
Powered rollers for consistent, steady movement
- 03
Durable, low-maintenance design
- 04
Variable speed control
- 05
Bi-directional operation
- 06
Configurable radius, width, and height (customizable)
- 07
Multiple roller types: Tapered / Sprocket Driven / Grooved
- 08
Selectable motor position: Right / Left / Center
- 09
Multiple drive options: Direct / Chain / Belt
Standard ranges
Read these as the envelope, not a fixed configuration. Length, width, height, finish and drive are set per application on the GA drawing.
- Radius
- R500/R700/R1000/R1500 / Customized
- Width
- 300-1000 mm
- Height
- 700-900 mm / Customized
- MOC
- SS 304 / MS
- Surface Finish
- SS Matt Finish / Bead Blast; MS Painting & Powder Coating
- Speed
- 3-20 m/min
- Roller Type
- Tapered / Sprocket Driven / Grooved
- Roller Diameter
- 38-60 mm
- Motor Position
- Right / Left / Center
- Voltage
- 220 V / 415 V
- Drive Type
- Direct / Chain / Belt
Where it runs
- Boxes and packaged goods handling
- Bottle capping lines
- Food grains transport
- Personal care and cosmetic products
- Sheet metal parts handling
- Vaccine bottles and pharma packaging
- Blister packs, tablets, and capsules
- Biscuits and food products
- Tray transport in automated lines
- Airports and baggage handling
- Assembly lines and automobile manufacturing
- E-commerce and warehousing
- Electronics manufacturing
- Food & beverage processing
- Packaging and waste management
